Product Information

Title	4-Jaw Scroll Chuck, 25" Cast-Iron Body, Plain Back, 2 PC Hard Rev. Jaws
Chuck Type	Scroll Self-Centering
Chuck Mount	Plain Back
Spindle Type	Requires Adapter
Chuck Dia (in)	25
Thru-Hole (in)	9.9213
Gripping Range Min-Max (in)	1.18 - 24.80
Chuck T.I.R (in)	0.004
Max RPM	500
Material	Cast Iron
Jaws	4
Jaw Type	2 PC Hard  Reversible
Weight Gross (lbs)	536.16
Includes	1 Set of Master and Hard Top Reversible Jaws, Adapter Mounting Bolts, Chuck Wrench, Hex Keys, Eye Bolts

Product Dimensions

D (in)	25
F  (in)	23.0709
E (H7) (in)	21.4567
d Hole (in)	9.9213
C (in)	.2756
H  (in)	5.315
h  (in)	3.622
M Mounting Bolt Thread	M16x2
M Mounting Bolt Length (in)	1.97
Mounting Bolt Qty	6

Crossover to Other Brands

Bison

7-840-2500

Accessories

Jaws
Hard Top Jaws (set)	TJ-PS4-630
Hard Master Jaws (set)	MJ-PS4-630
Soft Top Jaws (set)	STJ-PS1-630
Spare Parts
Chuck Wrench (1 pc)	W-P-630
Scroll (1 pc)	SC-PS-630
Pinion (1 pc)	PI-PS-630
Pinion Screw (1 pc)	PH-P-630
Chuck Mounting Bolts (1 pc)	MB-BS-630
Adapters
FM Machined Adapters A8	FM-630A8
FM Machined Adapters A11	FM-630A11
FM Machined Adapters A15	FM-630A15
FM Machined Adapters D8	FM-630D8
FM Machined Adapters D11	FM-630D11
FM Machined Adapters D15	FM-630D15
SM Semi-Finished Adapters A8	SM-630A8
SM Semi-Finished Adapters A11	SM-630A11
SM Semi-Finished Adapters A15	SM-630A15
SM Semi-Finished Adapters D1-8	SM-630D8
SM Semi-Finished Adapters D1-11	SM-630D11
SM Semi-Finished Adapters D1-15	SM-630D15
