6-Jaw Adjustable Scroll Chuck, 4" Steel Body, Hard Solid Jaws
Product Information
| Part Number | 1-104-0400 |
| Chuck Type | Scroll-Adjustable |
| Chuck Mount | Adjustable |
| Spindle Type | Requires Adapter |
| Chuck Dia (in) | 4 |
| Thru-Hole (in) | 0.787 |
| Gripping Range Min-Max (in) | .118 - 3.661 |
| Chuck T.I.R (in) | 0.0004 |
| Max RPM | 4000 |
| Material | Forged Steel |
| Jaws | 6 |
| Jaw Type | Hard Solid |
| Weight Gross (lbs) | 9.26 |
| Includes | 1 Set of Hard Solid ID & OD Jaws, Adapter Mounting Bolts, Fine Adjustment Screws, Chuck Wrench, Hex Keys |
Product Dimensions
| D (in) | 4 |
| C (in) | 0.51 |
| d Hole Max (in) | 0.787 |
| E (in) | 1.7717 |
| H (in) | 2.677 |
| F (in) | 3.2677 |
| h Jaw Height (in) | 0.63 |
| M Mounting Bolt Thread | M8x1.25 |
| Mounting Bolt Qty | 3 |
Crossover to Other Brands
| Bison | 7-868-8040 |
Accessories
| Jaws | |
|---|---|
| ID Hard Solid Jaws (set) | IJ-PS6-100 |
| OD Hard Solid Jaws (set) | OJ-PS6-100 |
| Soft Solid Jaws (set) | SJ-PS6-100 |
| Spare Parts | |
| Chuck Wrench (1 pc) | W-P-100 |
| Scroll (1 pc) | SC-PS-100 |
| Pinion (1 pc) | PI-PO-100 |
| Pinion Sleeve (1 pc) | PS-P-100 |
| Half Ring (1 pc) | HR-P-100 |
| Fine Adjustment Screws (1 pc) | FS-P-100 |
| Chuck Mounting Bolts (1 pc) | MB-BA-100 |
| Adapters | |
| Adapters Adjustable 1"-10UNS-2B | FLA-100T1 |
| Adapters Adjustable 1-1/2"-8UN-2B | FLA-100T2 |
| Base Plates | |
| Baseplates | F-BPA-125 |
| Baseplates (Haas) | F-BPA-125H16 |
