3-Jaw Scroll Chuck, 6" Cast-Iron Body, Direct Mount L00, 2 PC Hard Rev. Jaws
Product Information
| Title | 3-Jaw Scroll Chuck, 6" Cast-Iron Body, Direct Mount L00, 2 PC Hard Rev. Jaws |
| Chuck Type | Scroll Self-Centering |
| Chuck Mount | L00 |
| Spindle Type | L00 |
| Chuck Dia (in) | 6-1/4" |
| Thru-Hole (in) | 1.6535 |
| Gripping Range Min-Max (in) | 0.12 - 6.30 |
| Chuck T.I.R (in) | 0.0012 |
| Max RPM | 3000 |
| Material | Cast Iron |
| Jaws | 3 |
| Jaw Type | 2 PC Hard Reversible |
| Weight Gross (lbs) | 30.86 |
| Includes | 1 Set of Master and Hard Top Reversible Jaws, Chuck Wrench, Hex Key |
Product Dimensions
| D (in) | 6-1/4" |
| Taper Size | L00 |
| d Hole (in) | 1.6535 |
| Thread T (in) | 3-3/4" - 6 |
| G (in) | 2-3/4 |
| C (in) | 2.1260 |
| J (in) | .5512 |
| H (in) | 4.0551 |
| h (in) | 1.6930 |
Crossover to Other Brands
| Bison | 7-804-0641 |
Accessories
| Jaws | |
|---|---|
| Hard Top Jaws (set) | TJ-PS3-160 |
| Hard Master Jaws (set) | MJ-PS3-160 |
| Soft Top Jaws (set) | STJ-PS1-160 |
| Spare Parts | |
| Chuck Wrench (1 pc) | W-P-200 |
| Scroll (1 pc) | SC-PS-160 |
| Pinion (1 pc) | PI-PS-160 |
| Pinion Screw (1 pc) | PH-P-160 |
